ADS-NL2012-60D 20*12mm sm16703 RGB 12v led neon flex Strip Lighting


Input Voltage:DC12V/24V

Lamp Power:±14.4w

Led quantity:60leds per meter

Emitting Color:RGB

Led type:SMD5050 rgb

IC Chip:Ucs1903/sm16703

IC quantity:20pcs/m,3leds/ic

IP Grade:IP65

Beam angle:180°




Send Inquiry Leave Message

Product Detail


1. Flexible neon strip, this product is combined with PCB, leds and silicone tube, a pair of F/M connectors. As well as a series of gluing process to ensure good water and UV resistance.

2. It is a RGB programmable product, can achieve many different light effects by using a LED controller such as K-1000c.

3. The features of this product are high brightness, low power dissipation, long lifespan, low voltage decline and excellent thermal management and lumen maintenance.

4. This neon strip also can be ic inserted in led. 60 IC/m.

5. Customized requests are available, for example: non-waterproof or waterproof, and length (Maximum length is 5 meters)

6. This product has CE and RoHS certifications.


Packing & Weight

 1-21040G52J3G7.png  1-21040G52K4b8.png    1-21040G52PK63.png

Weight/5 meters




Carton size


5 meters

75 meters




 1-21040G52942458.png  1-21040G53020410.png

1. Amusement Park Rides Light

Ferris wheel, Carousels, Pirate ship, Pendulum, Tower and so on.

2. Advertisement Outdoor Signboard Backlight

Logo, Signage, Channel letter, Signs, Exposed luminous characters, Billboard and so on.

3. Stage Decoration Light

KTV, Disco, Bar, Night club and other stage light.

4. Commercial Light

Hotel, Shopping mall, Theater, Square and so on.

5. Home Decoration

Lighting, Home party, Christmas decoration, etc.

Cable Connection



1. The connector with 3 cables ( red, green, white) connect to controller

   Red-- V+ (DC12V)

   Green-- Data

   White-- GND

2. The connector with 2 cables (red, white) connect to power supply

   Red-- V+

   White-- V-
