Input voltage: DC12V
Lamp power: 7.7W
LED chip: SMD 5050 black or white LED
LEDs quantity: 36pcs
Color: RGB programmable
IP rating: IP66
Connector: Normal or waterproof connectors
Beam angle: ≥140°
1. This product is made up of PCB. plastic cover and base, a couple of 3-pins male and female connectors. As well as a series of gluing process to ensure good water and UV resistance.
2. It is a RGB programmable product, can achieve many different light effects by using a LED controller such as K-1000c.
3. The features of this product are high brightness, low power dissipation, long lifespan, low voltage decline and excellent thermal management and lumen maintenance.
4. Customized requests are available, for example: logo, waterproof connectors, transparent or milky cover, and length of cables.
5. This product has CE and RoHS certifications.
1. Amusement Park Rides Light
Ferris wheel, Carousels, Pirate ship, Pendulum, Bumper car, Tower and so on.
2. Advertisement Outdoor Signboard Backlight
Logo, Signage, Channel letter, Signs, Exposed luminous characters, Billboard and so on.
3. Stage Decoration Light
KTV, Disco, Bar, Night club and other stage light.
4. Commercial Light
Hotel, Shopping mall, Theater, Square and so on.
5. Kids Rides Decoration
Castles, Robot, Mini carousels, Car, Mini train etc.
Packing & Weight
1. Male connector (with pins) is signal input port, female connector (without pins) is signal output port.
2. We suggest that every 5pcs lights connect to the power supply in parallel to avoid voltage decline.
3. One controller can only support up to 2000 pixels, more than 2000 pixels, you need to cascade with multiple controllers.
